ThermoStable ON Ovens Gravity Convection Daihan Scientific |
|||||
|
Specification |
|||||
|
“ThermoStable ON” Model |
Standard Model |
||||
|
ON-32 |
ON-50 |
ON-105 |
ON-155 |
||
|
Window Model |
|||||
|
ON-W105 |
ON-W155 |
||||
|
Capacity |
32 Lit |
50 Lit |
105 Lit |
155 Lit |
|
|
Dimension |
Interior |
310 × 290 × 360 mm |
370 × 350 × 420 mm |
485 × 409 × 535 mm |
550 × 474 × 600 mm |
|
( W x D x H ) |
Exterior |
458 × 557 × 664 mm |
518 × 647 × 724 mm |
653 × 712 × 882 mm |
718 × 777 × 947 mm |
|
Heater Power |
500 W |
650 W |
1.4 kW |
1.6 kW |
|
|
Temp. |
Range |
Ambient Temp. +5 ℃ to 230 ℃ |
|||
|
Fluctuation |
± 0.5 ℃ at 100 ℃, ± 0.6 ℃ at 150 ℃ |
± 0.5 ℃ at 100 ℃, |
|||
|
± 0.8 ℃ at 150 ℃ |
|||||
|
Variation |
± 1.2 ℃ at 100 ℃, ± 2.2 ℃ at 150 ℃ |
||||
|
Sensor |
PT 100 |
||||
|
Control Resolution |
±0.1 ℃ |
||||
|
Heat-up Time |
30 min. to 100 ℃, |
30 min. to 100 ℃, |
35 min. to 100 ℃, |
||
|
43 min. to 150 ℃ |
45 min. to 150 ℃ |
50 min. to 150 ℃ |
|||
|
Recovery Time |
8 min. to 100 ℃, |
12 min. to 100 ℃, |
|||
|
( Door open 30 sec ) |
10 min. to 150℃ |
10 min. to 150℃ |
|||
|
Controller |
Digital Fuzzy Control by Advanced Microprocessor |
||||
|
Jog-Dial with Push Button |
|||||
|
RS232 Port |
Available to connect with PC |
||||
|
Display |
Digital LCD with Back Light |
||||
|
Timer |
99hr 59 min ( delay/continuous function ) |
||||
|
Material |
Internal |
Stainless steel ( #304 ) |
|||
|
External |
Powder Coated steel |
||||
|
Insulation |
Glass Wool |
||||
|
Shelves |
2 ea of Stainless steel Wire Shelves included, Load per Shelf : 16 kg |
||||
|
Ventilation hole with Stainless steel Cap, Hole Diameter 40 mm |
|||||
|
Ventilation |
1 ea |
2 ea |
|||
|
Circulation |
Gravity Convection Type |
||||
|
Safety device |
Over Temp. and Over Current Protector, Sensor Error Detector |
||||
|
Others |
UL/CUL Certified, CE Certified, GD-mark Storage Function ( Temp. and Time ) Locking Mode ( Jog-Dial Input Disabled ) Alarm ( Error Status and Timer-end ) |
||||
|
Net Weight |
36 kg |
44 kg |
69 kg |
78 kg |
|
|
Packing Size ( W x D x H ) |
562 × 664 × 747 mm |
622 × 754 × 807 mm |
743 × 819 × 1,068 mm |
808 × 884 × 1,133 mm |
|
|
Shipping Weight |
43 kg |
59 kg |
79 kg |
92 kg |
|
|
Power Consumption |
502 W |
674 W |
1390 W |
1566 W |
|
|
Energy Consumption, at 100°C |
90 Wh |
117 Wh |
187 Wh |
204 Wh |
|
|
Energy Consumption, at 150°C |
181 Wh |
230 Wh |
337 Wh |
398 Wh |
|
|
Power Supply |
1 Phase 120 V, 60 Hz or 230 V, 50/60 Hz |
||||
