TSU™ Series -86°C Upright Ultra-Low Temperature Freezers Thermo Scientific

Specifications

Product Size

TSU300D

TSU300V

Capacity  Shelf

125lb

Backup Systems

CO2 or LN2 Optional

Capacity  Shelf

303kg

2 ml Vial Cap.per Freezer

30000

Access Security

KeyLock Standard, Padlock Compatible, Key Card Optional

Chart Recorder

7-day ink or inkless Optional

Certifications/Compliance

cULus, CE listed

Data Outputs

RS-485, 4-20mA, dry contacts - standard

Description

Capacity : 14.9 cu. ft. (420.9 L); Holds 300 boxes; 208-230V/60 Hz

Capacity

14.9 cu. ft

Capacity

421L

Dimensions LxWxH Ext

37.6x27x78 in. (96x69x198cm )

Dimensions DxWxH Int

28.3x17.8x51.2 in (72x45x130cm)

Plug Type

NEMA 6-15

European

Temp.Range

-50° to -86°C

Voltage

208 to 230V

Doors

Single

Door Opening Recovery

13min

Electrical Requirements

208 to 230V 60Hz

Footprint

7.05 sq.ft

Energy Usage

15.3/17kW-hr/day

Health Monitoring

On Screen,Log File

Footprint

0.65 sq. meters

Inner Doors

4

Interior

Painted Steel - Standard, Stainless-steel - Optional

Line Voltage Indicator

Line voltage and Buck/Boost

Operating Modes

High Performance or Energy Efficiency

On-Board Datalogging

Standard

Peak Variation at -80⁰C

+5.5/-6.4°C

Regulatory Approvals

UL

CE

Smart View Compatibility

SmartView Compatible

Setpoint Security

Standard - Individual user names and passwords

Vial to Energy Ratio

2.36 watts/100 mL vials (box)

Vial to Footprint Ratio

4.255 vials/sq. ft

Vial to Footprint Ratio

46.154 vials/cu. m

Voltage Compensation

Buck/Boost

Warm up Time -80 ⁰C to -50 ⁰C

213min

Water Cooled

Optional

Amperage

9:00AM

Capacity

14.9cu. ft.,421L

Display

Touch ScreenLCD

Hertz

60Hz

50Hz

Holds

300boxes

Insulation

Vacuum Panel and Water Blown Foam

Shelves

3

Ship Weight

667lb

Ship Weight

303kg
