| Specifications |
| Size |
10" L x 3.0" W x 2.5" H ( 25.5 x 7.6 x 6.4 cm ) |
| Weight |
26 oz ( 738 g ) |
| Sensors |
Photoionization sensor with standard 9.8 eV or optional 10.6 eV or 11.7 eV lamps |
| Battery |
• Rechargeable, external field-replaceable lithium-ion battery pack |
| |
• Alkaline battery adapter |
| Operating Hours |
16 hours of operation |
| Display Graphic |
4 lines, 28 x 43 mm |
| Keypad |
1 operation and 2 programming keys, 1 flashlight on/off button |
| Direct Readout |
• VOCs as ppm by volume |
| |
• High and low values |
| |
• STEL and TWA |
| |
• Battery and shutdown voltage |
| |
• Date, time, temperature |
| Alarms |
• 95 dB buzzer ( at 12"/30 cm ) and flashing red LED to indicate exceeded preset limits |
| |
• High: 3 beeps and flashes per second |
| |
• Low: 2 beeps and flashes per second |
| |
• STEL and TWA: 1 beep and flash per second |
| |
• Alarms latching with manual override or automatic reset |
| |
• Additional diagnostic alarm and display message for low battery and pump stall |
| EMC/RFI |
Compliant with EMC directive ( 2004/108/EC ) |
| |
EMI and ESD test: 100 MHz to 1 G Hz 30 V/m, no alarm |
| |
Contact : ±4 kV |
| |
Air : ±8 kV, no alarm |
| IP Rating |
IP-65, unit running |
| Datalogging |
Standard 6 months at one-minute intervals |
| Calibration |
2-point or 3-point calibration for zero and span. Calibration memory for 8 calibration gases, alarm limits, span values and calibration dates |
| Sampling Pump |
• Internal, integrated flow rate at 400 cc/min |
| |
• Sample from 100' ( 30 m ) horizontally and vertically |
| Low Flow Alarm |
Auto shut-off pump at low-flow condition |
| Communication & Data Download |
• Download data and upload instrument set-up from PC through charging cradle or optional Bluetooth™ |
| • Wireless data transmission through built-in RF modem |
| Wireless Network |
Mesh RAE Systems Dedicated Wireless Network |
| Wireless Range ( Typical ) |
EchoView Host: LOS > 660 ft ( 200 m ) |
| |
ProRAE Guardian & RAEMesh Reader : LOS > 660 ft ( 200 m ) |
| |
ProRAE Guardian & RAElink3 Mesh : LOS > 330 ft ( 100 m ) |
| Safety Certifications |
• US and Canada : , Classified as Intrinsically Safe for use in Class I, Division 1 Groups A, B, C, D. |
| |
• Europe: ATEX II 2G EEx ia IIC T4 |
| |
• IECEx CSA 10.0005 Ex ia IIC/IIB GbT4 |
| Operating Temperature |
-4° to 122 °F ( -20° to 50 °C ) |
| Humidity |
0 % to 95 % RH ( non-condensing ) |
| Attachments |
Durable bright red rubber boot |
| Warranty |
3 years for 10.6 eV lamp, 1 year for 9.8. eV lamp, pump, battery, sensor and instrument |
| Wireless Frequency |
ISM license-free band. IEEE 802.15.4 Sub 1GHz |
| Wireless Approvals |
FCC Part 15, CE R&TTE, Others1 |
| Radio Module |
Supports Bluetooth or RM900 |
