DAIHAN-brand® Analog Ultrasonic Cleaners

“WUC-A”, Timer/Temp. Output Controller, with Certi. & Traceability with Stainless steel Flat Lid, Highly Effective Cleaning, up to 85℃, 0~30min, 28/40kHz Frequency, without Basket

Analog Ultrasonic Cleaner WUC-A.

Specification

Capacity

1.2 Lit. “WUC-A01H”

1.8 Lit. “WUC-A02H”

3.3 Lit. “WUC-A03H”

6 Lit. “WUC- A06H”

10 Lit. “WUC-A10H”

22 Lit. “WUC-A22H”

& Models

Frequency

40KHz

HF-Peak Out

72 W

75 W

124 W

168 W

265 W

379 W

Heating Temp.

65℃ Fixed

ambient to 85℃

Heating Power

86 W

86 W

172 W

172 W

258 W

275 W

Timer

None

0~30 min.

0~30 min.

0~30 min.

0~30 min.

0~30 min.

Drain-Valve

None

None

None

None

1/2" NPT

1/2" NPT

Tank inner W x D x H

150 × 135 × 60 mm

150 × 135 × 100 mm

240 × 140 × 100 mm

290 × 150 × 150 mm

290 × 240 × 150 mm

500 × 300 × 150 mm

Weight kg

1.8

2.5

4

5.3

7

11

Packing cm

20 × 20 × 19 mm

20 × 20 × 24 mm

32 × 20 × 29 mm

37 × 22 × 35 mm

43 × 32 × 36 mm

64 × 38 × 37 mm

Dimension W x D x H

Gross Weight kg

3

4

5

6

7

11

Power Consumption

158 W

161 W

296 W

340 W

523 W

654 W

Power Supply

1 Phase, AC 120 V, 60 Hz or AC 230 V, 50 / 60 Hz
