Bransonic CPXH Ultrasonic Bath
CPXH Series ( Digital timer with heat )
Order No.	Model 1800	Model 2800	Model 3800	Model 5800	Model 8800
Voltage 120V	CPX1800H	CPX2800H	CPX3800H	CPX5800H	CPX8800H
	CPX-952-118R	CPX-952-218R	CPX-952-318R	CPX-952-518R	CPX-952-818R
Voltage 230/240V	CPX1800H-E	CPX2800H-E	CPX3800H-E	CPX5800H-E	CPX8800H-E
	CPX-952-138R	CPX-952-238R	CPX-952-338R	CPX-952-538R	CPX-952-838R
Spec
Tank Capacity	Model 1800	Model 2800	Model 3800	Model 5800	Model 8800
Liters/Gallons	1.9/0.5	2.8/0.75	5.7/1.5	9.5/2.5	20.8/5.5
Tank Size ( L/W/D )
Inches	6 x 5.5 x 4	9.5 x 5.5 x 4	11.5 x 6 x 6	11.5 x 9.5 x 6	19.5 x 11.5 x 6
mm	150 x 140 x 100	230 x 140 x 100	290 x 150 x 150	290 x 240 x 150	495 x 290 x 150
Overall Size ( L/W/D )
Inches	9.9 x 12 x 11.9	13.3 x 12 x 11.9	15.6 x 12.5 x 14.8	15.6 x 15.8 x 14.9	23.5 x 18.3 x 15.4
mm	251 x 304 x 302	337 x 304 x 302	397 x 317 x 377	397 x 401 x 378	596 x 466 x 391
Weight
Pounds/Kilograms	7/3.2	9/4.1	12/5.4	14/6.4	26/11.8
Frequency	40 kHz
Drain	No		Yes
