DAIHAN-brand® Digital Ultrasonic Cleaner-set

“WUC-D”, Microprocessor Control, 3.3-/6-/10-/22- Lit. with Stainless steel Wire Basket & Flat Lid, Highly Effective Cleaning, up to 80℃, 0~60min, 40kHz Frequency

Digital Ultrasonic Cleaner WUC-D.

Specification

Capacity & Model

3.3 L “WUC - D03H”

6 L “WUC - D06H”

10 L “WUC - D10H”

22 L “WUC - D22H”

Frequency

40 kHz

40 kHz

40 kHz

40 kHz

HF-peak out

100 W

253 W

407 W

528 W

Heat temp.

Ambient to 80 '℃

Ambient to 80 '℃

Ambient to 80 ℃

Ambient to 80 ℃

Heating Power

172 W

172 W

258 W

344 W

Timer

0~30 min.

0~60 min.

0~60 min.

0~60 min.

Display

FND

Drain-valve

None

None

1/2" NPT

1/2" NPT

Tank inner W x D x H

240 × 140 × 100 mm

290 × 150 × 150 mm

290 × 240 × 150 mm

500 × 300 × 150 mm

Weight net

3.4 kg

5.8 kg

8 kg

12.9 kg

Packing Dim W x D x H

320 × 200 × 290 mm

360 × 220 × 350 mm

440 × 320 × 360 mm

640 × 380 × 370 mm

Gross Weight

3.7 kg

6.3 kg

8.5 kg

13.4 kg

Power Consumption

290 W

425 W

665 W

872 W

Power Supply

1 Phase, AC 120 V, 60 Hz or AC 230 V, 50 / 60 Hz
