Ultrasonic Pipet Washer AW31 Yamato Scientific

Features

With Return Current System for Smart Cleaning Efficiency

Dirty Liquid is drained by the force of Jet from Bottom Nozzle for good cleaning

Bath Basket is spinning constantly for good cleaning

Compact Design

Washing and Rinsing can be done in one Washer

Washable by Water-Soluble Alkaline Detergent

Specifications

Model

AW-31

Standard

Pipet Qty.

Pipet ( Max. 500 mm )

1 ml

264 pcs

5 ml

216 pcs

10 ml

136 pcs

Operation Water Amount

1 ~ 3 ℓ/min.

Ultrasonic Oscillator

High Frequency Output, 55 W, 28 kHz

Oscillation Plate: Stainless Steel, SUS430

Oscillator: Ball Ferrite

Bath Material

Clear Vinyl Chloride

Cabinet

Stainless Steel

Rack Dimensions

I.D. Φ 138 x H 540 mm

( Basket )

O.D. Φ146 x H 570 mm

External Dimensions

W 390 x D 400 x H 844 mm

Weight

Main Body : Approx. 18.5 kg, Basket : Approx. 1.0 kg

Power

AC100 V, 50/60 Hz, 2 A

Accessory

Rack

Manual Pump

Water Supply Hose I.D

12 mm x 1.5 m Length

Drain Hose I.D

25 mm x 1.5 m Length

Detergent
