Vacuum Leak Tester LT1001 Labindia-Analytical

LABINDIA Vacuum Leak Tester LT1001 is designed with utmost precision using top notch quality material and

advanced equipments .Our Leak Tester comprises of a polycarbonate desiccators housing to sustain the vacuum

for long time. Leak Tester apparatus finds wide application in numerous industries such as food ,

pharmaceuticals, chemical and many others. Also it is used to test the quality of packing processes in strips ,

blisters and sachets containing tablets , granulates and liquids .

Salient Features

128 X 64 Monochrome Graphical Display

Alphanumeric Keypad

20 Test and 10 Methods with date and time available.

Supplied in SS body

Selectable Pressure Units

LAN , RS - 232 ,Parallel Printer , External 80/48 Column and 40 Column Built in Mini Dot Matrix Printer available

Specifications

Vacuum Range

Upto 600 mm Hg

Vacuum Setting

Better Vacuum Stabilization Set Level

Pressure Unit

mm Hg / Psi / kPa

Desiccator

8 inch , 10 inch and 12 inch

Display

128 X 64 Monochrome Graphic Display

Keypad

Alphanumeric Keypad

Interface Port

LAN , RS - 232 ,Parallel Printer , External 80/48 Column and 40 Column Built in Mini Dot

Matrix Printer

Hold Time

Upto 30 minutes

Power

AC 230 V ±10 V , 50 Hz

Accessories

Polycarbonate desicator along with connecting tube. Instruction Manual

Date Format

USA/ASIA

Real Time Clock

Yes

Calibration

Easy Calibration

Validation

Easy Validation

Batch Test Results

20 Test and 10 Methods with date and time available

Print Report

Standard / User Defined

Print Report

Standard / User Defined

Password Protection

3 Tier Password Protection

Self Test

Facility to Scan ( Valves , Pump and Sensor )

Balance Interface

At Extra Cost ( Optional )
