Vacuum Drying Ovens Daihan Labtech LVO-2031P |
|
|
Specifications |
|
|
Ext.l dimensions ( W x D x H ) |
730 × 455 × 553 mm |
|
Int. dimensions ( W x D x H ) |
300 × 300 × 300 mm |
|
Volume, l |
27 Liter |
|
Temp. control range,°С |
+15 to 250 |
|
Temp. fluctuation, ±°С |
1.0 |
|
Temp. uniformity, ±°С |
±3.0 at 120 °С |
|
Vacuum range |
10 to 760 mmHg |
|
Controller |
Programmable PID Multi-function controller |
|
Display |
LED |
|
Timer |
99 min 59 sec. / 99 hr 59 min / 99 days 23 hours / Continuous Selectable |
|
Exterior material |
Epoxy powder coated steel |
|
Interior material |
3-4 mm thick stainless steel |
|
Outer door |
Tempered Glass Window with Silicone Packing |
|
Heater power |
1.5 kW |
|
Power supply |
110 V, 60 Hz ; 220 V, 50/60 Hz |
|
Vacuum Drying Oven Daihan Labtech LVO-2041P |
|
|
Specifications |
|
|
Ext. dimensions ( W x D x H ) |
830 × 555 × 660 mm |
|
Int. dimensions ( W x D x H ) |
400 × 400 × 400 mm |
|
Volume, l |
64 Liter |
|
Temp. control range,°С |
+15 to 250 |
|
Temp. fluctuation, ±°С |
1.0 |
|
Temp. uniformity, ±°С |
±3.0 at 120 °С |
|
Vacuum range |
10 to 760 mmHg |
|
Controller |
Programmable PID Multi-function controller |
|
Display |
LED |
|
Timer |
99 min 59 sec. / 99 hr 59 min / 99 days 23 hours / Continuous Selectable |
|
Ext. material |
Epoxy powder coated steel |
|
Interior material |
3-4 mm thick stainless steel |
|
Outer door |
Tempered Glass Window with Silicone Packing |
|
Heater power |
2.5 kW |
|
Power supply |
110 V, 60 Hz ; 220 V, 50/60 Hz |
|
Vacuum Drying Oven Daihan Labtech LVO-2051P |
|
|
Specifications |
|
|
Ext. dimensions ( W x D x H ) |
930 × 660 × 757 mm |
|
Int. dimensions ( W x D x H ) |
500 × 500 × 500 mm |
|
Volume, l |
125 |
|
Temp. control range,°С |
+15 to 250 |
|
Temp. fluctuation, ±°С |
1.0 |
|
Temp. uniformity, ±°С |
±3.0 at 120°С |
|
Vacuum range |
10 to 760 mmHg |
|
Controller |
Programmable PID Multi-function controller |
|
Display |
LED |
|
Timer |
99 min 59 sec. / 99 hr 59 min / 99 days 23 hours / Continuous Selectable |
|
Ext. material |
Epoxy powder coated steel |
|
Int. material |
3-4 mm thick stainless steel |
|
Outer door |
Tempered Glass Window with Silicone Packing |
|
Heater power |
3.0 kW |
|
Power supply |
110 V, 60 Hz ; 220 V, 50/60 Hz |
|
Vacuum Drying Oven Daihan Labtech LVO-2030 |
|
|
Specifications |
|
|
Ext. dimensions ( W x D x H ) |
730 × 455 × 553 mm |
|
Int. dimensions ( W x D x H ) |
300 × 300 × 300 mm |
|
Volume, l |
27 Liter |
|
Temp. control range, °С |
+5 to 250 |
|
Temp. fluctuation, ±°С |
1.0 |
|
Temp. uniformity, ±°С |
±3.0 at 120 °С |
|
Vacuum range |
10 to 760 mmHg |
|
Controller |
Programmable PID Multi-function controller |
|
Display |
LED |
|
Timer |
99 min 59 sec. / 99 hr 59 min / 99 days 23 hours / Continuous Selectable |
|
Ext. material |
Epoxy powder coated steel |
|
Int. material |
3-4 mm thick stainless steel |
|
Outer door |
Tempered Glass Window with Silicone Packing |
|
Heater power |
1.5 kW |
|
Power supply |
110 V, 60 Hz ; 220 V, 50/60 Hz |
