Multi Gas Detector Ventis MX4 Indsci

Specifications

Warranty

Two- year warranty, including sensors and battery

Case material

Polycarbonate w/ protective rubber overmold

Dimensions

103 mm x 58 mm x 30 mm ( 4.1" x 2.3" x 1.2" ) - Ventis lithium-ion battery version

172 mm x 67 mm x 66 mm ( 6.8" x 2.6" x 2.6" ) - Ventis with pump lithium-ion battery version

Weight

182 g ( 6.4 oz ) - Ventis, lithium-ion battery version

380 g (13.4 oz) - Ventis with Pump, lithium-ion battery version

Temperature Range

-20°C- 50°C ( -4°F-122°F )

Humidity Range

15%-95% Non-condensing ( continuous )

Display/Readout

Backlit Liquid Crystal Display ( LCD )

Power Source/Run Time

Rechargeable slim extended lithium-ion battery

(18 hours typical @ 20 ºC) without pump

Rechargeable lithium-ion battery

(12 hours typical @ 20 ºC) without pump

Rechargeable extended-range lithium-ion battery

(20 hours typical @ 20 ºC) without pump

(12 hours typical @ 20 ºC) with pump

Replaceable AAA alkaline battery

(8 hours typical @ 20 ºC) without pump

(4 hours typical @ 20 ºC) with pump

Alarms

Ultra-bright LEDs, loud audible alarm ( 95 dB at 30 cm ), and vibrating alarm

Sensors

Combustible gases/methane - Catalytic Diffusion

O2, CO/H2 low, CO, H2S, NO2, SO2 - Electrochemical

Measuring Ranges

Combustible Gases

0-100% LEL in 1% increments

Methane (CH4)

0-5% of vol. in 0.01% increments

Oxygen (O2)

0-30% of vol. in 0.1% increments

Carbon monoxide (CO/H2 low)

0-1,000 ppm in 1 ppm increments

Carbon monoxide (CO)

0-1,000 ppm in 1 ppm increments

Hydrogen sulfide (H2S)

0-500 ppm in 0.1 ppm increments

Nitrogen dioxide (NO2)

0-150 ppm in 0.1 ppm increments

Sulfur dioxide (SO2)

0-150 ppm in 0.1 ppm increments

Supplied with Monitor

Calibration Cup (without pump), Sample Tubing (with pump)

Languages

English (1), French (2), Spanish (3), German (4), Italian (5), Dutch (6), Portuguese (7), Russian (9), Polish (A), Czech (B), Chinese (C), Danish (D), Norwegian (E), Finnish (F), Swedish (G), Japanese (J)

Order Information

MOST COMMON INSTRUMENT ConFIGURATIONS (UL/CSA)

PART NO.

PART NO. DEscriptION

VTS-K1234100y0z

Ventis MX4, LEL, CO, H2S, O2, Slim Extended Li-ion, Desktop Charger, Black

VTS-K1232111y0z

Ventis MX4 with pump, LEL, CO, H2S, O2, Extented Li-ion, Desktop Charger, Safety Orange

VTS-K1034100y1z

Ventis MX4, LEL, CO, O2, Slim Extended Li-ion, Desktop Charger, Soft Case, Black

VTS-K1032110y1z

Ventis MX4 with pump, LEL, CO, O2, Extended Li-ion, Desktop Charger, Soft Case, Black

VTS-K5234101y0z

Ventis MX4, LEL, SO2, H2S, O2, Slim Extended Li-ion, Desktop Charger, Safety Orange

VTS-K1434100y1z

Ventis MX4, LEL, CO, NO2, O2, Slim Extended Li-ion, Desktop Charger, Soft Case, Black

VTS-K1432111y0z

Ventis MX4 with pump, LEL, CO, NO2, O2, Extended Li-ion, Desktop Charger, Safety Orange

y = Agency Certification: 1 = UL/CSA, 2 = ATEX/IECEx, 3 = MSHA, 4 = ANZEx,

5 = China Ex, 7 = EAC(GOST-R/GOST-K), 8 = KC(HOSHA), 9 = INMETRO, A = MED, D = TIIS

z = Language: 1 = EN, 2 = FR, 3 = ES, 4 = DE, 5 = ITA, 6 = DUT, 7 = PT, 9 = RUS, A = POL, B = CZE,

C = CN, D = DAN, E = NOR, F = FIN, G = SWE, J = JPN
