Vortex Mixer VM-96T / VM-96A Lab Companion
Features
Well-balanced design and optimized safety features.
Low-profile with small footprint ideal for use on lab benches and within fume hoods or clean benches.
On touch operation mode, real-time and dynamic mixing made even with gentle touch.
- Every point of the top surface is highly reactive to gentle touch due to widely built in sensitive sensors.
Selective mixing modes with variable speed control knob.
- VM-96A : Touch / Continuous / High-continuous.
- VM-96T : Touch / Continuous.
Built-in LED lamps in case of VM-96A for easy recognition of the mixing mode selected.
Sparkless BLDC motor adopted for safety, quick acceleration, and low maintenance.
Built-in safety features against overload and over current.
Chemically resistant polypropylene molded exterior.
Wide range of accessories available.
Specifications
Model		VM-96A	VM-96T
Speed range ( rpm )		Max. 3000
Speed control		Scale
Operating mode		Touch/Continuous/High-continuous	Touch/Continuous
Motion		Orbital
Orbit size ( mm, inch, dia.)		4 / 0.16
Max. load ( kg / lbs )		0.5 / 1.1
Motor rating input / output ( W )		12/6
Material	Platform	Silicone
	Body	Polypropylene
	Motor type	BLDC ( Brushless Direct Current )
Dimensions	Platform ( W x D ) ( mm )	76 x 76 / 3 x 3 Inch
	Exterior 1) ( W × D × H )	154 × 210 × 84 mm / 6.1 x 8.3 x 3.3	148 x 159 x 77 mm / 5.8 x 6.3 x 3
	Net weight ( kg / lbs )	3 / 6.6	2.6 / 5.7
Protection class ( DIN EN 60529 )		IP 42	-
Electrical requirements		AC 100 V to 240 V, 50/60 Hz
Cat. No.	KR plug	AAH360215K	Persian blue	Orange
			AAH361215BK	AAH361215RK
	US plug	AAH360215U	Persian blue	Orange
			AAH361215BU	AAH361215RU
