VORTEX MIXER VM Gemmy |
|
|
Model |
VM-300 |
|
Specification |
|
|
Dimension |
130 x 165 x 180 mm |
|
Eccentric Ø |
5.6 mm |
|
Modes |
Touch / Switch |
|
Speed ( single tube ) |
3150 rpm |
|
Speed ( 3” pad ) |
1800 rpm |
|
Standard accessory |
Single tube head |
|
Optional accessory |
3” multi-tube head |
|
Net weight |
5.0 kg |
|
Model |
VM-300P |
|
Specification |
|
|
Diamension |
145 x 170 x 185 mm |
|
Eccentric DIA |
4.2 mm |
|
Modes |
Touch/Switch |
|
Speed |
3200 rpm |
|
Speed |
1500 rpm ( with 3" pad ) |
|
Model No |
VM-370 |
|
Specification |
|
|
Temperature |
4ºC – 60ºC |
|
Humidity |
40% – 90% |
|
Sea level altitude |
≤ 4000 meters |
|
Atmospheric pressure range |
700hPa to 1060hPa |
|
Overall dimension |
450 x 300 x 125 mm approx |
|
Net weight |
7 kg ( 17.5 Lb.) approx |
|
Roller number |
7 rollers |
|
Roller size |
32 mm ( Ø ) x 320 mm ( L ) |
|
Speed |
Fix at 40 rpm ( ±3 rpm ) |
|
Motor |
Gear motor 24 V, 5.17 W |
|
Timer |
Mechanical 180 minutes |
|
Operation |
Choice of Continuous and Intermittent |
|
Rocking range |
19mm diameter |
|
Max load |
5 kg ( 11 Lb.) |
|
Loading capacity |
5 ml : 18 pc/ 10 ml : 12 pc/ 15 ml : 12pc/ 50 ml/12 pc |
|
Current |
110 V/0.4 A; 220 V/0.23 A |
|
Power source |
110 V, 220 V, 50/60 Hz |
