Water Bath Gemmy

Shaking water bath

Model No : YCW-012S

Specification :

- Choice of digital or analog setting to meet your requirements.

- Built-in circulating stirrer ensures uniform bath temperatures.

- Heating lamp indicates the heating element is energized or stabilized

- Tube rack and flask platform can be raised and lowered to suit the lengths of different vessel and test tubes. They are detachable and easy for installment.

- An induction motor produces a 20mm circular motion with 0 dB ensures maintenance free.

- Built-in microprocessor-based digital controller simultaneously displays the actual temperature.

- The shaking bath is ideal for applications that require a reciprocating shaking motion with a temperature uniformity of ±0.1 ºC.

- Tube rack or flask platform are removable when the shaking motion is not required.

- Regulates shaking stroke by turning the control knob from 20 – 200 rpm to your desired applications.

- Functions over temperature alarm and shutoff automatically.

- Audible alarm is activated and shut off power to 2ºC above the set point.

- Indicators of Power、Heating、PV、SV、Alarm etc.

- Function temperature recalibration when the actual temperature cannot match the display temperature.

- Timer is available upon request when the time is critical to the user.

Model No : YCW-01 Gemmy

Volume 22 L.

Temp setting Analog

Temp readout Thermometer

Temp preset N.A.

Max temperature 100 ºC

Temp stability ±0.2 ºC

Temp uniformity ±0.01 ºC

Temp control ON/OFF

Timer N.A.

Over-heat shutout Yes

Heating element 1.0 KW

Model No : YCW-010 Gemmy

Volume 22 L & 11 L.

Temp setting Digital

Temp readout LED digital

Temp preset . N.A.

Max temperature 99.9 ºC

Temp stability ±0.01 ºC

Temp uniformity ±0.01 ºC

Temp control PID

Timer N/A

Over-heat shutout 2 ºC to set point

Heating element 1.0 KW

Model No : YCW-010E Gemmy

Specification :

Volume 22 L & 11 L.

Temp setting Digital

Temp readout LED digital

Temp preset N.A.

Max temperature 99.9 ºC

Temp stability ±0.01 ºC

Temp uniformity ±0.01 ºC

Temp control PID

Timer YES

Over-heat shutout 2 ºC to set point

Heating element 1.0 KW

Model No : YCW-03S Gemmy

Specification :

Volume 22 L.

Temp setting Thumb switch

Temp readout LED digital

Temp preset 25 º, 37 º, 56 ºC

Max temperature 100 ºC

Temp stability ±0.05 ºC

Temp uniformity ±0.01 ºC

Temp control PID

Timer N.A.

Over-heat shutout Yes

Heating element 1.0 KW

Model No : YCW-05 Gemmy

Specification :

5 LITERS , ANALOG , THERMOMETER , HEATING ELEMENT

- Providing a desired test through a thermostatic temperature with 5 ºC above ambient to 100 ºC, ideal for biological, clinical research, medical, bio-chemical, industry and education laboratory.

- Molded bath with rounded corners and seamless stainless steel sides ensures efficient circulation and easy for cleaning.

- Equipped with immersion heating element sheathed with stainless steel.

- Improve temperature uniformity by rotating water stirrer to direct flow to various areas of the tank.

- Optional concentric rings cover minimizes heat loss when you suspend flasks  or other vessels in the bath.
