Water Bath Heating System ERB-16W Electrolab

Features

- Supports up to 16 bottles of 100 ml each

- Magnetically coupled drive and precise speed control from 5 to 50 RPM with soft start facility

- Programmable temperature in the water bath from 30 °C to 50 °C

- Snap fitting of bottles for easy placement and removal

- Robustly built clear polycarbonate water bath to withstand high temperatures

Specification

Water bath

Clear polycarbonate

 Water Capacity

62 liter

 Bath size ( L x W x H )

( 472 x 404 x 376 ) mm

Speed control

Speed range

1 to 60 RPM

Display

3 digit seven segments LED

Resolution

1 RPM

Accuracy

+ 1 RPM

Motor

Stepper motor

Drive type

Magnetically coupled

Temperature Indicator/Controller

Set temperature range

30 °C to 50 °C

Display

4 digit seven segments LED

Resolution

0.1 °C

Control accuracy

+0.2 °C

Heater

3 KW/230V AC

Circulation

Magnetically coupled pump, Flow rate : 11 ltrs/min

Power supply

230V AC +10 %, 50 Hz, 3.2 KW

Dimensions ( L x W x H )

( 635 x 400 x 480 ) mm ( approx. )
