Water Bath WEB Series Daihan Scientific

Specification

No. of Extraction Holes & Model

4 Places

6 Places

8 ( 4 × 2 ) Places

“WEB - 4”

“WEB - 6”

“WEB - 8”

Temp. Range & Accuracy

Ambient +5 ℃ to 100 ℃,  ±0.2 ℃

Temp. Uniformity & Sensor

±1.0℃,   PT100

Heating Power

1.4 kW

1.8 kW

1.4 kW × 2

Timer & Alarm

99 hr 59 min ( Delay & Continuous run ), Error status & Timer-end

Display

Digital LCD with Back - Light Function

Controller

Digital Fuzzy Controller with Jog-Shuttle Switch ( Turn+Push )

Safety Circuit

Over-Temp./-Current protection, Sensor Error Detection, Leakage Breaker

Material

Stainless steel ( ＃304 )-Internal,  Powder Coated steel-External,

Stainless steel-Holding frame

Lid & Top Opening Dia.

Concentric Ring Cover Sets included, Φ110 mm

Drain Valve

Mounted

Dimension ( W × D× H )

Internal

610 × 160 × h160 mm

910 × 140 × h 160 mm

610 × 290 × h 160 mm

External

720 × 245 × h 275 mm

975 × 245 × h 275 mm

720 × 375 × h 275 mm

Packing Size and

710 × 310 × h 300 mm

1,030 × 320 × h 370 mm

880 × 420 × h 300 mm

Gross Weight

18 kg

25 kg

34 kg

Power Supply

1 Phase, AC 120 V / 60 Hz  or 230 V, 50 / 60 Hz
