Water Bath WNE Series Memmert

Model

WNE 7

WNE 10

WNE 14

 WNE 22

WNE 29

WNE 45

Temp. range in °C

Min. 5°C above ambient up to +95 °C with additional boiling mode ( +100 °C )

Resolution of display and setting accuracy

0,1 °C up to +99,9 °C / 1°C from 100 °C

Controller

LED of all set parameters, such as temp. and alarm values (0,1°C resolution) as well as time values

Timer

Digital timer from 1 min. up to 999 hours

Calibration

On controller

Temp. control

2 Pt100 sensors Class A in 4-wire-circuit, mutually monitoring & taking over the performance at the same temp. value

Temp. control

30 °C above max. Temp. of the bath

Temp. control

Controller TWW protection class 3.1 or  overtemp. limiter TWB protection class 2, set-up menu by customer

Temp. control

Approx. 10 °C above the set temp. (fixed value)

Autodiagnostic system

Fuzzy-supported PID microprocessor controller

Alarm

Visual and acoustic alarm

Heating Baths

Corrosion-proof large-area heating on three sides

Dimensions WxHxD in mm

240x140x210

350x140x210

350x140x290

350x220x290

590x140x350

590x220x350

Interior

Easy-to-clean interior, made of stainless steel, reinforced by deep drawn ribbing, material no. 1.4301 ( ASTM 304 ), laser-welded

Volume

7 l

10 l

14 l

22 l

29 l

45 l

Liquid level min. mm

(H) 97

(H) 97

(H) 9

(H) 177

(H) 105

(H) 177

Liquid level max. mm

(I) 120

(I) 120

(I) 120

(I) 200

(I) 120

(I) 200

Dim. w(D)xh(G)xd(E) mm

468x337x356

578x337x356

578x347x436

578x405x436

818x343x516

818x401x516

Voltage

230 V, 50/60 Hz

Electrical load W

1200

1200

1800

2000

2400

2800

Installation

Min. wall spacing on all sides is 80 mm. The min. spacing from the top of the bath to the next ceiling is 750 mm.

Ambient temp.

+5 °C to +40 °C

Humidity rh

Max. 80 %, non-condensing

Overvoltage category

II

Pollution degree

2

Transport information

The appliances must be transported upright

Dimensions incl. Carton mm

570x450x420

670x450x380

670x530x400

670x530x460

910x610x400

910x610x460

Approx N. W kg

11

13

15

16

24

26

Approx G.W. Carton kg

16

19

21

23

31

33
