Xplorer GLX - PS-2002 Data Logger Pasco Scientific

Overview

For over a decade the Xplorer GLX datalogger has been used in thousands of science classrooms around the world. But its long and successful run is coming to an end. The GLX is scheduled to be discontinued and a limited quantity of them remain.

Features

Large backlit LCD -- visible in both sunlight and low light

Stand-Alone or  Computer Interface

4 universal sensor ports -- use with over 60 PASPORT sensors

4 built-in sensors ( 2 temperature, sound, voltage )

Collect Data in the Classroom or the Field

Graphs, tables, digits, and meter displays

The world's first graphing logger for science that truly stands alone . . . the Xplorer GLX captures, analyzes, annotates, stores and prints data quickly and seamlessly, without being connected to a computer. A science lab wherever you need it. Also, connect to a computer and unleash the full power of the new PASCO Capstone software.

Built for Science Measurement

Large 320 x 240 backlit transflective LCD grayscale display. Readable in a dark room as well as sunlight.

8 sensor ports total--4 dedicated for included sensors and 4 open ports.

Includes 2 temperature, sound and voltage sensors.

12 MB Internal Memory - Useful for high data collection rates and storing multiple data files.

Real-time graphing and calculations from Floating Point Processor--even instant calculations on live data as it is collected

Built-in graphing calculator with expression editor.

Built-in dual independent function generators.

Built-in speaker for sound output.

Specifications

Display

320 x 240 backlit transflective LCD grayscale displays

Sensor Ports

8 Total, including built-in Sound Sensor, Voltage Sensor, and Temperature Sensors ( 2 ).

4 dedicated: Sound, Voltage and 2 Temperature

4 open--connect any PASPORT Sensor

Maximum Sampling Rate

50,000 Hz

Calculation Engine

50 MHz FPU: Real-time graphing and instant calculations from Floating Point Processor.

Memory

12 MB of built-in flash memory

Sensor Compatability

All PASPORT Sensors

All ScienceWorkshop Sensors using PASPORT Analog and Digital Adapters

Battery

Rechargeable 1700 mAH NiMH battery

USB

2 USB built-in ports
